Articles Posted by the Author:

  • 86DUINO ENJOY AUTO Exchange

    印匠 ENJOY AUTO Exchange The 86Duino ENJOY AUTO Exchange is built with CNC machined metallic frame to provide a rigid structure for the printer assembly, which helps minimize vibration and provides a stable environment to deliver optimal print quality. The intuitive 86Duino Enjoy is designed with simple calibration, enabling you to easily enjoy and replicate […]


  • 86Sense – RM320

    The 3-axis force torque sensor Features ● Robotics ● Biped robot ● Cutting measurement ● Industrial test benches ● Mechanical linkage ● Structure status Main specifications Measuring range Force range Fz ±2000N Moment range Mx, My ±40 N-m Signal noise Force in Z 0.1 N Moment in X, Y 0.005 N-m Data output rate >500Hz […]


  • SyncAxes 6 – 6-Axis closed loop stepper motor controller

    6-Axis closed loop stepper motor controller Features ● 6 Axes stepper motor simultaneously ● Close loop operation ● Selectable microstepping and phase current ● Operating current up to 4.5A ● USB, SD card and LAN ● 12V – 30V voltage range ● 6 x Encoder interface ● 6 x Digital input ● 9 x High-speed […]


  • 86servo-T120

    T120 Features ● 12N-m & 110RPM output ●POSITION, SPEED and CURRENT control with/without trajectory tracking ●16,384PPR absolute + 904K PPR relative encoder ●32bit multi turn control range ●Dual port 6Mbps RS-485 with Modbus ●EtherCAT module available ●44 (W) x 44 (H) x 60 (L) mm Main specifications Processor DMP Vortex86EX2 533MHz+300MHz 32-bit x86 Position Sensor […]


  • 86DUINO ENJOY AUTO Exchange

    印匠 ENJOY AUTO Exchange The 86Duino ENJOY AUTO Exchange is built with CNC machined metallic frame to provide a rigid structure for the printer assembly, which helps minimize vibration and provides a stable environment to deliver optimal print quality. The intuitive 86Duino Enjoy is designed with simple calibration, enabling you to easily enjoy and replicate […]


  • About 86Duino ENJOY

    86Duino ENJOY The 86Duino Enjoy is built with CNC machined metallic frame to provide a rigid structure for the printer assembly, which helps minimize vibration and provides a stable environment to deliver optimal print quality. The intuitive 86Duino Enjoy is designed with simple calibration, enabling you to easily enjoy and replicate your creation with minimal […]


  • 86Duino ONE

    Overview ● Vortex86EX Processor 300MHz 32-bit x86 128MB/1GB DDR3 LAN USB 2.0 Micro-SD ● Open-Source Hardware ● Support DOS, Windows, Linux ● Arduino-Compatible IDE 86Duino is an open-source embedded platform based on Vortex86EX SoC, easy-to-use hardware and software integrated. This Arduino-compatible board can support many x86 O/S as well as those running on the original […]


  • 86Duino ZERO

    Overview ● Vortex86EX Processor 300MHz 32-bit x86 128MB/1GB DDR3 LAN USB 2.0 Micro-SD ● Open-Source Hardware ● Support DOS, Windows, Linux ● Arduino-Compatible IDE ● Arduino “Leonardo” form factor 86Duino is an open-source embedded platform based on Vortex86EX SoC, easy-to-use hardware and software integrated. This Arduino-compatible board can support many x86 O/S as well as those […]


  • 86Duino EduCake

    Overview ● Vortex86EX Processor 300MHz 32-bit x86 128MB DDR3 LAN USB 2.0 Micro-SD ● Open-Source Hardware ● Support DOS, Windows, Linux ● Arduino-Compatible IDE EduCake is designed to be compatible with Arduino series. It is an all-in-one design with an integrated bread board. Many electronic components, sensors and accessories can be easily connected or replaced […]


  • BOM/Part List for DM-220 (Bread Board)

    BOM/Part List for DM-220 (Bread Board)

    No. Q’ty Location Describe 1 6 C1,C2,C5,C6,C7,C8 SMD CAP. 0603    0.1uF  / 25V , +-10% ,  X7R , MLCC 2 6 C3,C4,C9,C10,C11,C12 SMD CAP. 1206    47uF /6.3V ,+-20%,  X5R, MLCC 3 34 D1,D2,D3,D4,D5,D6,D7,D8, “LD. 3”     BAT54SN3 (KL4) SMD D9,D10,D11,D12,D13,D14, D15,D16,D17,D18,D19,D20, D21,D22,D23,D24,D25,D26, D27,D28,D29,D30,D31,D32, D33,D34 4 2 F1,F2 F0    FSMD100-0805R  FUZETEC SMD 0805 […]
